QTS Company Ltd was incorporated in June 2010 under the Companies Act, 1963 (Act 179) of the Republic of Ghana. Ever since we commenced business in 2013, we have earned ourselves a track record of successful execution as general contractors and developers in the building industry.
We pride ourselves in having a strong rapport with our clients and suppliers, a dedicated and experienced management team and an experienced construction crew with a commitment to continuous improvement.
QTS embodies a professional, highly skilled and experienced team with over 60 years of combined industry experience. This multinational team has executed projects of various sizes from the USA and Canada to the far reaches of Asia and now Africa. With some of Ghana’s most intelligent minds on our team; giving us the depth and indigenous ‘on the ground’ experience, we always come up on top of our game. As of this writing, our team is 250-member strong and growing by the week.
DEVELOPER, BUILDER, CONTRACTOR
WHO ARE WE ?
QTS Company Ltd sets out to create a different kind of building Company – one focused on bringing comfort and cost savings to its clients. Guided by this vision, QTS being the nation’s leading ICF builder brings tremendous cost savings through its rapid building systems and significant energy cost reduction with the ICF building technology which also provides a more reduced noise and healthier living environment.
QTS has its own manufacturing plant which produces the energy efficient and environmentally friendly Insulated Concrete Form (ICF) blocks it uses for construction. The company’s competitive strategy is the Backward Integration Model which literally means the company has all the competences and in house resources to deliver a project from conceptualization to completion. An organization where quality meets excellence, technology meets aesthetics and passion meets perfection.
Today the company is committed to delivering only the best in each and every home and neighborhood it builds. The company’s goal is customer satisfaction and creating an unsurpassed reputation for quality and integrity in the building industry.
VISION
To provide exceptional construction services and quality affordable housing utilizing alternative building systems and innovative construction methodologies. Thereby delivering to the marketplace, a product and service of exceptional value in a reasonably short period of time.
MISSION
The mission of QTS Company Ltd is to be a leader in our industry by being an innovative developer, construction company, and successful surveyor of middle-income housing. Leveraging our experience, resources, and relationships, we will differentiate ourselves from the competition by providing products and services of exceptional value through innovation.
Projects
Custom Page Layout
Create a unique page layout with additional buttons and sections for your construction business.
Easy Page Navigation
Allow users to easily navigate through your website with custom page designs and features.
Expandable Sections
Add extra pages and sections as needed to showcase your construction projects and services.
Expandable Sections
Add extra pages and sections as needed to showcase your construction projects and services.
Add extra pages and sections as needed to showcase your construction projects and services.
Expandable Sections
Portfolio
On-going projects.
ICF Technology
WHAT ARE INSULATED CONCRETE FORMS (ICF)?
Insulated Concrete Forms are a light-weight, rigid foam insulating block concrete forming system for both above and below grade steel reinforced concrete wall construction. ICFs are stacked and locked together (similar to “Lego” set) to quickly build interior and/or exterior walls of various heights and thicknesses depending on the engineering requirements. ICF walls can take many different shapes depending on the architectural requirements.
Insulated Concrete Forms (ICF) provides design professionals, architects, home owners and contractors the freedom and versatility to design and build a structure the way it was envisioned. Building with ICF gives the opportunity to build faster and more efficient, while building an eco-friendly structure with substantial benefits that contribute to long-term energy savings.
BENEFITS OF ICF
ICFs improve the thermal performance of the walls is one of the most immediate and cost-effective ways to reduce running energy costs. ICFs thermal resistance rating (RSI) ranging between 2.6 RSI to 4 RSI (R-15 to R-25). The bigger the number the better the material is able to resist heat transference. On average, ICF structures require 32% less energy to cool and 44% less energy to heat.
Thermal Benefits
Energy Efficiency
The combination of the Insulated Concrete Forms and the concrete core acts as a mass wall and blocks air infiltration, allowing buildings to save significantly on their cooling and heating costs.
ICF is:
•Termite Resistant
•Mold Resistant
•Crack Resistant
•Pest Resistant
•Waterproof
•No Nail Pops
•Insulation
•Superior Sound
ICF wall assembly delivers 60% less air filtration than a traditionally built wall. This means that energy efficiency is significantly better, leading to savings in cooling and heating costs, as well as improved indoor air quality.
Reduced Air Filtration
ICF act as an effective sound barrier by dampening sound vibrations from unwanted outside noise, ideal for both residential and commercial construction, providing STC (Sound Transmission Class) rating as high as STC 50 and as high as STC 56 for a 16cm (6.25”) ICF wall.
Insulated Concrete Form technology is straightforward assembly, is easy to learn and even easier to put into practice.
It will take less time to train a worker on how to use and construct ICF wall systems then to train a worker to be a qualified block mason.
Another advantage is there is less need for heavy equipment; therefore, less need for workers with heavy equipment training.
Sound Resistance
Structural Performance
Structures that are built with ICF are up to 25%stronger than other concrete walls due to the slow curing of the concrete within the insulated panels which creates walls up to 4 times stronger than wood. The high structural performance of ICF helps buildings withstand earthquakes, hurricanes and tornadoes, making them an ideal wall system for high-risk geographies.
ICF can withstand winds of up to 402 kph (250 mph). Building with ICF will allow a building to be robust and stand against tough weather conditions. Ideal for any purpose built building but particularly for government and institutional buildings as this will display to the public the conscious effort to make these buildings safe and strong enough to withstand most unfavourable weather conditions.
Fire Resistance
Of all construction materials, concrete is one of the most resistant to heat and fire. Experience shows that concrete structures are more likely to remain standing through fire than structures made of other materials. Concrete, does not burn.
Unlike steel, it does not break down until it is exposed to thousand of degrees Celsius – far from what is present in a typical house fire. The foam in ICF are manufactured with flame-retardant additives. Insulated Concrete Forms has a fire protection rating of up to 4 hours.
The strength of Insulated Concrete Forms comes from the solid concrete core.
Durability
Resistance
An Insulated Concrete Form structure is built to last and retains its value longer. The main structural element in an ICF building is reinforced concrete, which offers substantially better durability and requires less maintenance and repairs over its lifetime.
The ICF wall minimizes interior temperature swings and reduces the amount of heating or cooling needed.
Non-ICF Structure
Water Resistance
ICF products do not absorb water and are thus waterproof. Exposure to water does not cause swelling. Water vapor will pass through the product but water will not.
Skilled Workers
Insulated Concrete Form technology is straightforward assembly, is easy to learn and even easier to put into practice.
It will take less time to train a worker on how to use and construct ICF wall systems then to train a worker to be a qualified block mason.
Another advantage is there is less need for heavy equipment; therefore, less need for workers with heavy equipment training.
Speed of Construction
For conventional wood, steel stud, concrete block or monolithic concrete construction to show performance equal to ICF, additional materials, labour and equipment would be needed. With Insulated Concrete Forms, one does not need additional air barriers, vapor barriers which would add more labour and materials.
An ICF structure typically costs less than other wall assemblies that have comparable energy efficiency and structural, fire and noise performance. Also, ICF Structures take half the time to construct and therefore, helps accelerate the project’s schedule.
ICF is cost effective. Builders who use Insulated Concrete Forms report savings in the shell construction costs. This is attributable to many factors such as speed and ease of wall erection, reduced waste, ease and speed of mounting windows and doors, etc.
The larger the structure, the greater the savings could be. Savings are generally in the range of 10% and as high as 20% in multi-storey buildings. The reduction of waste alone will produce savings.
Resistance to Pest and Rot
EPS provides no nutrient value to plants, animals and microorganisms. Therefore, bacteria and fungi do not multiply. The EPS used by Pro Form System will not rot and is highly resistant to mildew.ICF is of no nutritional value to microorganisms, insects, rodents and plants. No bacteria or fungi therefore do not develop in ICF structures.
Cost Effectiveness
ICF is cost effective. Builders who use Insulated Concrete Forms report savings in the shell construction costs. This is attributable to many factors such as speed and ease of wall erection, reduced waste, ease and speed of mounting windows and doors, etc. The larger the structure, the greater the savings could be. Savings are generally in the range of 10% and as high as 20% in multi-storey buildings. The reduction of waste alone will produce savings.
ICF APPLICATIONS IN DIFFERENT STRUCTURES
Single-Family Homes
High-Rise Residencies
• Same tradesmen can install basement and above ground walls.
• Stronger, more durable construction with fewer deficiencies.
• Ready to meet & exceed new and upcoming building codes
• Lower cooling, heating and operating costs
• Various shapes
• ICF buildings often come in at a lower cost per square foot than masonry and pour-in place construction
• Construction is uninterrupted by weather
• Reduced number of tradespeople required
• Significantly lower cooling
Commercial/Institutional
• Significantly lower heating, cooling & operating costs
• Ready to meet & exceed new and upcoming building codes
• Construction is uninterrupted by weather conditions
• Reduced number of trades/people required
Multi-Family Residencies
• Cost-effective fire & sound separation walls
• Same tradesmen can install basement and above ground walls
• Stronger, more durable construction with fewer deficiencies
• Occupants and owners will enjoy significantly lower cooling, heating, & operating costs
